Emergency stop with 2 positive opening 69002
Produkten kan skilja sig från bild

Emergency stop with 2 positive opening

contacts in a IP65 enclosure
Art.Nr.: 69002
Vikt: 0.114 kg
Tillverknings land:  DE
Tillgänglig
Find similar Product
Ställ en fråga
 Rekommendera produkten
 Produktjämförelse
Listpris per styck:

Beskrivning

E-Stop 42 2NC L M12(8)
with M12 connection
8-pole
Emergency-Stop button
2 NC (positively-opening)
LED-Ring can be lit
Certificate
Certificate
Certificate

Technical Data
Operating voltage 1...36 V DC (UR: 30 V DC)
Operating current 1.5 A
Contact bounce time max. 10 ms
LED Light max. 30 V AC/DC typ. 4 mA (24 V DC)
General data
Mounting method with clip on back
Material contact Ag Ni
Temperature range -25...+70 °C (storage temperature -25...+85 °C)
Lambda (d) 20% (N/C)
B10d 250 000
Mech./ elect. life 50 000 actuations, load-temperature dependent
Protection IP65
Connection M12 (8-pole)
Dimensions H×W×D 52×124×42 mm
Contact Layout
PIN 1 N/C 1
PIN 2 N/C 1
PIN 3 N/C 2
PIN 4 N/C 2
PIN 5 n.c.
PIN 6 n.c.
PIN 7 (X2/-)
PIN 8 (X1/+)
Product article number of manufacturer 69002

ECLASS-6.0 27371244
ECLASS-6.1 27371244
ECLASS-7.0 27371244
ECLASS-8.0 27371244
ECLASS-9.0 27371244
ECLASS-10.1 27371244
ECLASS-11.1 27371244
ECLASS-12.0 27371244
ETIM-5.0 EC002034
EAN 4048879594219
Förpackningsenhet 1
Kundens tullnummer 85365080


Uppgifter angående artikel:
  • Ladda ner Datablad
  • Ladda ner Approval: UL Registered US 69002_E479949-NISD2_ur_z_b.pdf
  • Ladda ner Certificate: TÜV  69002_B0318910009-09.02.2025_tuev_z_c.pdf
  • Ladda ner Construction files: DXF 69002_dxf_x_a.zip
  • Ladda ner Construction files: P8 69002_p8_2_51.zip
  • Ladda ner Construction files: STP 69002_stp_x_a.zip
  • Ladda ner Document: Installation guide 69000_ina_2_12.zip
  • Ladda ner Information: Certificate of conformity Murrelektronik GmbH 20-10-21_(1) California Prop65 No Warning_DoC_z_b.pdf
  • Ladda ner Information: Certificate of conformity Murrelektronik GmbH 04-02-23_(1) China RoHS 2 e_DoC_z_a.pdf
  • Ladda ner Information: Certificate of conformity UKCA 69002_06-03.22_uk_z_a.pdf
  • Ladda ner Information: EU declaration of conformity 69002_06-03.22_ce_z_c.pdf
  • Ladda ner Information: Safety Codes 69000_SYSTEMA_TB9_x_22.zip
