General data
| Mounting method | 2-hole screw mounting |
|---|---|
| Temperature range | 0...+55 °C (storage temperature -20...+70 °C) |
| Protection | IP67 |
| Dimensions H×W×D | 42.7×63×225 mm |
Input
| Sensor supply US | 24 V DC (EN 61131-2), max. 200 mA (M12 female), short-circuit and overload protected |
|---|---|
| Type | for 3-wire sensors or mechanical switches, PNP |
Parameterization
| PIN 4 | Input |
|---|---|
| PIN 2 | Input |
Connections
| Fieldbus | Ethernet 10/100 Mbit/s; Push Pull RJ45 Data connector |
|---|---|
| Sensor-system/actuator supply | Push Pull Power connector, max. 12 A |
| I/O ports | M12, 5-pole, A-coded |
PROFINET
| Specification | V2.2, Conformance Class B |
|---|---|
| Addressing | DCP |
| FSU (Fast-Start-Up) | max. 500 ms |
Diagnostic
| Communication status | via LED |
|---|---|
| Diagnostic via LED | per module and channel |
| Diagnostic via BUS | per module and channel |
| Actuator warning | per channel via LED and BUS |
| Monitoring - under voltage | yes |
| Monitoring - no voltage | yes |
| Short-circuit and overload | yes |
| Cable break | per port |
Kommersiella uppgifter
| EAN | 4048879051736 |
|---|---|
| eClass | 27242604 |
| Förpackningsenhet | 1.000 |
| Kundens tullnummer | 85176200 |
| Tillverknings land | DE |
