MASI68 I/O EXTENSION MODULE K3
Produkten kan skilja sig från bild

MASI68 I/O EXTENSION MODULE K3

4 digital inputs, 4 digital, passive safety outputs
Art.Nr.: 56428
Vikt: 0.22 kg
Tillgänglig
 Produktjämförelse
Listpris per styck:
Expansion module
DI4 - 0.2 A DO4 - 1.6 A (E) - 8× M12 (AB) (Y) (K3)
Output groups up to PLd (EN ISO 13849-1) can be switched off via safety relays
Connection cables are in the online shop under "Connection Technology".
Housing fully potted.
Technical Data
ASI-Power 24 yes
Bus voltage (AS-Interface) 26.5...31.6 V DC
Profile (IO/ID/ID2 code) S-7.A.7
Addressing via master or M12 connection and programming device
Address range 1...62 (1...31 A or B)
Total current max. 250 mA
General data
Mounting method screw fixing
Temperature range -20...+60 °C (storage temperature -20...+70 °C)
Protection IP68
Dimensions H×W×D 126×50×34.5 mm
Output
M12 configuration Y-wiring
Supply voltage 24 V DC external (18...30.2 V DC) EN 61131-2
Total current max. 4 A
Switching current per output max. 2 A (short-circuit and overload protected)
Input
Sensor supply US max. 200 mA from AS-Interface (short-circuit and overload protected)
Type for 3-wire sensors or mechanical switches, PNP
Connections
Fieldbus A-coded
I/O ports M12, 5-pole
Diagnostic
Communication status via LED
Diagnostic via LED per module
Monitoring - no voltage yes
Kommersiella uppgifter
EAN 4048879048866
eClass 27242604
Förpackningsenhet 1.000
Kundens tullnummer 85176200
Tillverknings land DE
Data cableVisa alla
Sensor-actuator cableVisa alla

Uppgifter angående artikel:
  • Ladda ner Datablad
  • Ladda ner Approval: UL Listed CA 56428_E201820-NRAQ7_ULC_Z_A.PDF
  • Ladda ner Approval: UL Listed US 56428_E201820-NRAQ_UL_Z_A.PDF
  • Ladda ner Certificate: ASI  56428_90101_ASI_Z_A.PDF
  • Ladda ner Construction files: DXF 56427_DXF_X_A.ZIP
  • Ladda ner Construction files: P8 56418_P8_2_30.ZIP
  • Ladda ner Construction files: P8 56428_P8_2_50.ZIP
  • Ladda ner Construction files: STP 56427_STP_X_A.ZIP
  • Ladda ner Document: Installation guide 56428_INA_6_19.PDF
  • Ladda ner Document: User manual 56431_HDB_X_25.ZIP
  • Ladda ner Information: EU declaration of conformity 56428_5045-04.16_CE_Z_E.PDF
  • Ladda ner Information: MTTF Report 56428_SN29500(40°C)-BERECHNUNGV1.4_MTTF_P_D.PDF
