DATAEAGLE 7050 ME
Du kanske också gillar
General data
| Standards | IEC 61010-2-201, EN 61204-3, EN 55011 B, EN 61000-3-2, SEMI F47 |
|---|---|
| Mounting method | DIN-rail mountable TH35 (EN 60715) |
| Temperature range | -40...+60 °C, ...+70 °C derating (storage temperature -40...+80 °C) |
| Relative humidity | 5...95%, no condensation |
| Protection | IP20 |
| Efficiency | 92.7% (110 V AC); 94.5% (230 V AC) |
| Connection | Push-In spring clamp terminals |
| Dimensions H×W×D | 123×50×138 mm |
Output
| Output voltage | 24 V DC (SELV), ±1%; 24...28 V adjustable |
|---|---|
| Power Boost | Iout N × 150% (min. 4 s) |
| LED display | LED (green): OK; LED (red): overload, overheating or short-circuit |
| Output current | 5 A |
| Mains failure bridging time | min. 30 ms (100 V AC); 5 A (24 V DC) |
| Ripple | max. 50 mV eff/rms |
| Spikes | max. 200 mV ss/pp |
| Unit protection | short-circuit and overload protected |
| Parallel usage/serial usage | max. 5 units/max. 2 units |
Input
| Input voltage | 85...265 V AC/90...250 V DC |
|---|---|
| Input current | 1.3 A (100 V AC); 0.61 A (240 V AC) |
| Inrush current after 1 ms | max. 5.5 A (230 V AC) |
| Power factor | 0.87 (230 V AC) |
| Frequency | 50...60 Hz |
| Input fuse (internal) | 6.3 A (T) |
Kommersiella uppgifter
| EAN | 4048879402903 |
|---|---|
| eClass | 27049002 |
| Förpackningsenhet | 1.000 |
| Kundens tullnummer | 85044090 |
| Tillverknings land | CZ |
