MTPS POWER SUPPLY 1/2-PHASE, SMOOTHED
IN: 230/400+/-15VAC OUT: :24V/0,5ADC
| Art.Nr.: | 85400 |
| Vikt: | 1.28 kg |
| Tillverknings land: | CZ |
Slut på lager - Kontakta oss för leveransdatum
Beskrivning
Current: 0.5 A
Output rating: 12 W
This power supply units meet the (EN 61000-3-2) standard for harmonic current.
Output rating: 12 W
This power supply units meet the (EN 61000-3-2) standard for harmonic current.
Tekniska data
General data
| Standards | EN 61558-2-6, EN 62041 category I, EN 55011 B, EN 61000-3-2 |
|---|---|
| Mounting method | DIN-rail mountable TH35-15 (EN 60715) or for key-hole mounting |
| Temperature range | -20...+60 °C, no condensation |
| Fixing centers a×b×c | 96×60×5.5 mm |
| Dimensions H×W×D | 108×87×124 mm |
Output
| Output voltage | 24 V DC (SELV) |
|---|---|
| Output suppression | LED, VDR and smoothing capacitor |
| Output fuse | 0.5 A (T) |
| Output current | 0.5 A |
| Ripple | max. 5% eff/rms |
Input
| Input voltage | 230/400 ±15 V AC |
|---|---|
| Input fuse (external) | 0.125 A (T) (230 V AC); 0.1 A (T) (400 V AC) |
| LED display | LED (green) for input voltage |
| Input current | 0.10 A (230 V AC); 0.06 A (400 V AC) |
| Frequency | 50...60 Hz |
| Product article number of manufacturer | 85400 |
|---|
Kommersiella uppgifter
| ECLASS-6.0 | 27049002 |
|---|---|
| ECLASS-7.0 | 27049002 |
| ECLASS-8.0 | 27049002 |
| ECLASS-9.0 | 27040701 |
| ETIM-5.0 | EC002540 |
| EAN | 4048879079877 |
| Förpackningsenhet | 1 |
| Kundens tullnummer | 85044095 |
