MEN POWER SUPPLY 1/2-PHASE, SMOOTHED
IN: 115/230+/-10VAC OUT: :24V/15ADC
| Art.Nr.: | 85355 |
| Vikt: | 8.8 kg |
| Tillverknings land: | CZ |
Slut på lager - Kontakta oss för leveransdatum
Beskrivning
Current: 15 A
Output rating: 360 W
This power supply units meet the (EN 61000-3-2) standard for harmonic current.
For any mounting position at vertical wall.
Output rating: 360 W
This power supply units meet the (EN 61000-3-2) standard for harmonic current.
For any mounting position at vertical wall.
Tekniska data
General data
| Standards | EN 61558-2-6, EN 62041 category I, EN 55011 B, EN 61000-3-2 |
|---|---|
| Mounting method | Key-hole mounting |
| Temperature range | -20...+60 °C, no condensation |
| Fixing centers a×b×c | 126×104×6.5 mm |
| Dimensions H×W×D | 138.5×135×181.5 mm |
Output
| Output voltage | 24 V DC (SELV) |
|---|---|
| Output current (Ta 60/40 °C) | max. 15 A (115 V AC); 18 A (230 V AC) |
| Output suppression | LED, VDR and smoothing capacitor |
| Ripple | max. 5% eff/rms |
Input
| Input voltage | 115/230 V AC ±10 V AC |
|---|---|
| Input fuse (external) | 8 AT (115 V AC); 4 AT (230 V AC) |
| Input current | 5.6 A (115 V AC); 2.8 A (230 V AC) |
| Frequency | 50...60 Hz |
| Product article number of manufacturer | 85355 |
|---|
Kommersiella uppgifter
| ECLASS-6.0 | 27049002 |
|---|---|
| ECLASS-7.0 | 27049002 |
| ECLASS-8.0 | 27049002 |
| ECLASS-9.0 | 27040701 |
| ETIM-5.0 | EC002540 |
| EAN | 4048879080026 |
| Förpackningsenhet | 1 |
| Kundens tullnummer | 85044095 |
