MCS POWER SUPPLY 3-PHASE,

IN: 340-460VAC OUT: 24-28V/20ADC
Art.Nr.: 85097
Alternativ produkt:    85692
Vikt: 2.42 kg
Tillverknings land:  CZ
Slut på lager - Kontakta oss för leveransdatum
 Produktjämförelse
Listpris per styck:
Ladda ner Easy-Import-Export

Beskrivning

INPUT: 3× 340...460 V AC
OUTPUT: 24...28 V DC
Current: 20 A
Certificate
Certificate

Input
Input voltage 3× 340...460 V AC
Primary fusing external max. 3× 6 A
Input current 3× 1.4 A
Inrush current after 1 ms max. 25 A
Frequency 50...60 Hz
Output
Output voltage 24 V DC (SELV), ±1%; 24...28 V adjustable
LED display LED (green) for output voltage
Selectable switch-off mode front sided plug link (automatic re-start or definite shut-off)
Output current 20 A (+60 °C); 20...24 A (+40 °C)
Mains failure bridging time min. 10 ms (400 V AC)
Ripple max. 20 mV eff/rms
Spikes max. 100 mV ss/pp
Unit protection short-circuit and overload protected
Parallel usage/serial usage yes/yes
General data
Standards IEC 61010-2-201, EN 61204-3, EN 55011 A
Mounting method DIN-rail mountable TH35 (EN 60715)
Temperature range 0...+60 °C (storage temperature -25...+85 °C)
Relative humidity 30...90%, no condensation
Efficiency 90%
Dimensions H×W×D 170×84×201 mm

ECLASS-6.0 27049002
ECLASS-6.1 27049002
ECLASS-7.0 27049002
ECLASS-8.0 27049002
ECLASS-9.0 27040701
ECLASS-10.1 27040701
ECLASS-11.1 27040701
ECLASS-12.0 27040701
ETIM-5.0 EC002540
EAN 4048879080477
Förpackningsenhet 1
Kundens tullnummer 85044083


Uppgifter angående artikel:
  • Ladda ner Produkt-PDF
  • Ladda ner Construction files: DXF 85097_dxf_x_a.zip
  • Ladda ner Construction files: STP 85097_stp_x_a.zip
  • Ladda ner Document: Installation guide 85097_ina_4_11.pdf
  • Ladda ner Information: Certificate of conformity Murrelektronik GmbH 20-10-21_(1) California Prop65 No Warning_DoC_z_b.pdf
  • Ladda ner Information: Certificate of conformity Murrelektronik GmbH 05-02-23_(2) China RoHS 2 20EEP_DoC_z_a.pdf
  • Ladda ner Information: Certificate of conformity Murrelektronik GmbH 13-11-20_(2) RoHS REACh exception 7cI_DoC_z_c.pdf
  • Ladda ner Information: Certificate of conformity UKCA 85097_45-10.20_uk_z_a.pdf
  • Ladda ner Information: EU declaration of conformity 85097_45-10.20_ce_z_c.pdf
  • Ladda ner Information: MTBF Report 85097_SN29500(40°C)-BerechnungV1.4_mtbf_p_a.pdf
