M8 male 90° with cable, 180°  7000-08912-6950500
Produkten kan skilja sig från bild

M8 male 90° with cable, 180°

PUR 5x0.25 bk UL 5m

Art.Nr.: 7000-08912-6950500
Alternativ produkt:    7000-08912-6950750
Vikt: 0.085 kg
Tillverknings land:  CZ
Listpris per styck:
Ladda ner datablad Ladda ner Easy-Import-Export


Male 90°
M8, 5-pole
with cable sleeves
Attention: Contact carrier turned to 180°!
Plastic housings with good resistance against chemicals and oils.
The resistance to aggressive media should be individually tested for your application. Further details on request.
Further cable lengths on request.

Cable length 5 m
Side 1
Tightening torque 0,4 Nm
Mounting method inserted, screwed
Coating contact gold plated
Family construction form M8
Material contact Copper alloy
Material PUR
No. of poles 5
Width across flats SW9
Electrical data | Supply
Operating voltage AC max. 30 V
Operating voltage DC max. 30 V
Installation | Connection
Mounting set M8 x 1
Mating cycles min. 100
Device protection | Electrical
Pollution Degree 3/2
Insulation resistance min. 100 MΩ
Mechanical data | Material data
Coating of fitting nickel plated
Material screw connection Zinc die-casting
Environmental characteristics | Climatic
Operating temperature min. -25 °C
Operating temperature max. 80 °C
Additional condition temperature range depending on cable quality

Cable identification 695
Material wire Cu wire, bare
Resistor (core) max. 58 Ω/km (20 °C)
Single wire Ø (core) 0.1 mm
Construction (core) 32× 0.1 mm (multi-strand wire class 6)
Diameter (core) 5× 0.25 mm²
AWG similar to AWG 24
Material wire isolation PP
Wire-Ø incl. isolation 1.2 mm ±5%
Stranding combination 5 wires twisted around central filler
Shield no
Material jacket PUR
Outer-Ø (jacket) 4.7 mm ±5%
Color jacket black
Nominal voltage 300 V
Test voltage 3000 V AC
Temperature range (fixed) -25...+80 °C
Temperature range (mobile) -10...+80 °C
Bend radius (moving) 7.5× outer Ø
No. of bending cycles (C-track) max. 5 Mio. (25 °C)
Travel speed (C-track) max. 3 m/s
Acceleration (C-track) max. 5 m/s²

ECLASS-6.0 27279218
ECLASS-7.0 27279218
ECLASS-8.0 27279218
ECLASS-9.0 27060311
ECLASS-10.1 27060311
ECLASS-11.1 27060311
ECLASS-12.0 27060311
ETIM-5.0 EC001855
Förpackningsenhet 1
GTIN 4048879783330
Kundens tullnummer 85444290

Uppgifter angående artikel:
  • Produkt-PDF
  • Approval: UL Registered CA 7000-08912-695xxxx_E325311-CYJV8_urc_z_a.pdf (A)
  • Approval: UL Registered US 7000-08912-695xxxx_E325311-CYJV2_ur_z_a.pdf (A)
  • Information: Certificate of conformity Murrelektronik GmbH 10-11-20_(1) RoHS REACh exception 6c_DoC_z_a.pdf (04)
  • Information: Certificate of conformity Murrelektronik GmbH 07-02-23_(5) China RoHS 2 50EEP_DoC_z_a.pdf (01)
  • Information: Certificate of conformity Murrelektronik GmbH 20-10-21_(1) California Prop65 No Warning_DoC_z_b.pdf (01)
  • Information: Certificate of conformity UKCA con_01-10.21_uk_z_b.pdf (B)
  • Information: EU declaration of conformity con_01-10.21_ce_z_b.pdf (B)
