7/8'' female 0° with cable

PUR 5x1.5 gy UL/CSA+drag ch. 10m
Art.Nr.: 7000-78021-9611000
Alternativ produkt:    7000-78021-9621000
Vikt: 1.295 kg
Tillverknings land:  CZ
Slut på lager - Kontakta oss för leveransdatum
 Produktjämförelse
Listpris per styck:

Beskrivning


Female straight
7/8" (5-pole)
Power cable
with cable sleeves
Further cable lengths on request.
Plastic housings with good resistance against chemicals and oils.
The resistance to aggressive media should be individually tested for your application. Further details on request.
Certificate

Form
Form 78021
Technical Data
Operating voltage max. 230/400 V AC/DC
Operating current per contact max. 12 A
Locking of ports Screw thread 7/8" (recommended torque 1.5 Nm) self-securing
Protection IP67 inserted and tightened (EN 60529)
Locking material Zinc die casting, matte nickel plated
General data
Temperature range -25...+85 °C, depending on cable quality
Cables
Cable identification 961
Cable Type 3 (PUR)
Cable weight [g/m] 129,8 g
Material wire Cu wire, bare
Resistor (core) max. 13.3 Ω/km (20 °C)
Single wire Ø (core) 0.15 mm
Construction (core) 84× 0.15 mm (multi-strand wire class 6)
Diameter (core) 5× 1.5 mm²
AWG similar to AWG 16
Material wire isolation PP
Material property (wire isolation) CFC-, halogen-, cadmium-, silicone- and lead-free
Shore hardness (wire isolation) 60 ±5 D
Wire-Ø incl. isolation 2.3 mm ±5%
Color/numbering of wires bl, bk, wh, br, num; gnye longitudinally striped
Stranding combination 5 wires twisted around central filler
Shield no
Material jacket PUR
Material property (jacket) CFC-, halogen-, cadmium-, silicone- and lead-free, matt, low-adhesion, machine easy to process, abrasion-resistant, hydrolysis and microbial resistant
Shore hardness (jacket) 90 ±5 A
Outer-Ø (jacket) 8.0 mm ±5%
Color jacket gray
chemical resistance good resistance to oil, gasoline and chemicals (EN 60811-404)
thermal resistance flame retardant UL 1581 VW1 / CSA FT1 / IEC 60332-1, IEC 60332-2-2
Nominal voltage 1000 V AC
Test voltage 10.0 kV
Current load capacity to DIN VDE 0298-4
Temperature range (fixed) -50...+80 °C, (+90 °C at max. 10 000 operating hours)
Temperature range (mobile) -25...+80 °C, (+90 °C at max. 10 000 operating hours)
Bend radius (fixed) 7.5× outer Ø
Bend radius (moving) 10× outer Ø
No. of bending cycles (C-track) max. 5 Mio. (25 °C)
Travel speed (C-track) max. 3.3 m/s
Acceleration (C-track) max. 5 m/s²
Torsion stress ±180°/m
No. of torsion cycles max. 2 Mio. (25 °C)
Torsion speed 35 cycles/min
Product article number of manufacturer 7000-78021-9611000
Cable length 10 m

ECLASS-6.0 27279218
ECLASS-7.0 27279218
ECLASS-8.0 27279218
ECLASS-9.0 27060311
ECLASS-10.1 27060311
ECLASS-11.1 27060311
ECLASS-12.0 27060327
ETIM-5.0 EC001855
EAN 4048879135207
Förpackningsenhet 1
Kundens tullnummer 85444290
