M8 female 0° A-cod. screw terminal  7000-08671-0000000
Produkten kan skilja sig från bild

M8 female 0° A-cod. screw terminal

4-pol., 0,14 - 0.5mm², 4 - 5,5mm, shielded

Art.Nr.: 7000-08671-0000000
Vikt: 0.053 kg
Tillverknings land:  DE
Tillgänglig
Listpris per styck:
Ladda ner datablad Ladda ner Easy-Import-Export

Beskrivning

Female straight
M8, 4-pole
shielded
Screw terminals
Connection cross section: 0.14...0.5 mm²

Form
Form 08671
Technical Data
Operating voltage max. 60 V
Rated surge voltage 1.5 kV
Operating current per contact max. 4 A
Material group III
Locking of ports Screw thread (M8×1 mm) recommended torque 0.4 Nm, self-securing
Connection cross section 0.14...0.5 mm²
Sealing range (cable Ø) 4...5.5 mm
Protection IP67 inserted and tightened (EN 60529)
Locking material Brass, nickel plated
Over voltage category III
General data
Material contact Gold plated bronze
Pollution Degree 3
Temperature range -40...+85 °C
Dimensions H×W×D 49×14×14 mm
Product article number of manufacturer 7000-08671-0000000

ECLASS-6.0 27279221
ECLASS-7.0 27440104
ECLASS-8.0 27440104
ECLASS-9.0 27440102
ECLASS-10.1 27440102
ECLASS-11.1 27440102
ECLASS-12.0 27440116
ETIM-5.0 EC002635
Förpackningsenhet 1
GTIN 4048879224468
Kundens tullnummer 85366990


Uppgifter angående artikel:
  • Produkt-PDF
  • Construction files: STP 7000-08671_stp_x_a.zip (A)
  • Document: Installation guide 7000-08671-0000000_ina_x_01.pdf (01)
  • Information: Certificate of conformity Murrelektronik GmbH 10-11-20_(1) RoHS REACh exception 6c_DoC_z_a.pdf (04)
  • Information: Certificate of conformity Murrelektronik GmbH 07-02-23_(5) China RoHS 2 50EEP_DoC_z_a.pdf (01)
  • Information: Certificate of conformity Murrelektronik GmbH 20-10-21_(1) California Prop65 No Warning_DoC_z_b.pdf (01)
